3d carving machine with oscillating knfie for advertisement
|Payment Type:||L/C,T/T,D/P,Money Gram,Western Union|
|Terms of Trade:||FOB,CIF|
|Min. Order:||1 Set/Sets|
|Delivery Time:||7-15 Days|
|Packaging:||All Cnc Router are packed with standard inner plastic wrap and outer plywood case, inner package would be help to tight all the small parts in the package.|
|Place of Origin:||Jinan, Shandong Province, China|
|Supply Ability:||50 sets/month|
Model No.: UT-1325
3d carving machine with oscillating knfie for advertisement
Cnc oscillating foam knife cutting machine
Cnc lathe machine apply for shoes making industry, apparel and fashion cloth industry, automotive interior industry, luggage industry, package industry, decoration industry, electronic industry, composite materials industry etc. It can process fabric, knitting vamps, non-woven, leather, rexine, cotton, felt, silk, lace, polyester, fleece, soft shell, jeans, alcantara, neoprene, corrugated board, cardboard, white board, gray board, sticker, PVC film, foam board, artificial leather, leather, gasket, sponge, prepreg, acrylic, honeycomb board, fiberboard, epoxy resin board, organic glass, car mat, fiber, composite material and other soft materials, etc.
CNC Oscillating Knife / Tangential Knife technology, we use a high quality carbide blade to cut through the media, that will bring a same result as a hand cut scalpel!Mounted on a strong stepping motor, we use a 4th computer rotation axes to make perfect lines and curves.
Applications: Leather, Carpet, Carton, Wood, MDF, PVC, Acrylic, Carboard, Rubber, Corrugated box, Foam, Leather strip; composites, cardboard, Corrugated board, Honeycomb paper, Plastic film, Fiber paper, plastic box, rebound rubber, rubber cloth, gasket, PP,PE, EVA, PTFE, ETFE.
---Why choose Oscillating Knife Cutting Machine
- Auto quick tool changer, and Fast speed with good quality;
- Advanced Syntech system, easy and pricise operation with the handle;
- No messy cut resulting from melting or fraying.
- Cut soft media with perfect edges and corner.
- No bad hazardous fumes from laser.
- No dust from cutting, no dust collector needed but a clean environment.
- No burn edges, uniform in color;
- No smell from melting or burning.
- Perfect square corner versus router because we go up in the air to turn the blade direction, giving a perfect corner.
---Feature of chinese Oscillating Knife Cnc Router:
- Effective working area: 1300*2500*200mm(could be customized)
- Heavy duty thicker structure
- 3 heads auto changing working: Spindle+Oscillating knife+CCD camera
- Multech control system
- Servo motor&driver
- Helical rack & Gear
- Taiwan TBI ball screw
- PMI25 square linear guide way for X,Y,Z axis
- Automatic Tool sensor calibration
- Automatic oil lubrication system
- Rotary device: 200mm diameter and 2000mm length(optional)
---Parameters of Cnc Oscillating Knife Cutting Machine
PS: All the working area and specifications can be customized according to your requests.
1) CCD camera
The machine comes with a camera to realize the vision function.
2) Oscillatin knife
Could be cutting all kinds of soft materials, like paper, leather, carton, KT board etc.
3) Machine head
The vision system CNC Router machine comes standard with 5.5kw high frequency air cooled spindle. This precision spindle requires no maintenance. Fully programmable speeds from 6000 to 24000 RPM, more powerful and less noise.
4) Vision system
- CCD and dual color adjustable LED light
- Software: TroCCDCut
- System Requirement: WinXP,Vista,Win7,Win8,Win10
- Accurate positioning cutting
- Subtle stretching and auto compensation
- Auto recognition cutting
- Real-time contour recognition
- Compatible with various graphic design software
5) JMC hybrid servo motor&driver+Japan SHIMPO reducer
Japan SHIMPO reducer install on the driving motor, makes the motor is more powerful, and having a longer time service life.
6) XY axis dustproof structure
X axis dustproof device design, Y axis double sheet metal protection design, pinion dustproof sheet metal design.
The patent design pressing clamp is convenient for the user to assemble and disassemble the material.
The spindle is fixed on the high quality aviation aluminum T061/6063 plate, the plate is machined by high precision CNC machining center.
Precision 1.25module helical rack+Taiwan TBI ball screw
1. Higher efficiency than traditional ball screws
2. Gothic groove shape, the shaft direction clearance can be adjusted to a minimum and can be easily transferred
3. The internal circulation method is applicable to many different scenes, and the circulation method is selected according to its own needs.
4. Use rigorous materials, high heat treatment and processing technology to supply durable products.
11) Tool sensor
Automatic tool calibration pad allows for easy and accurate [Z" zero position for single and multiple tool changes through the program.
---Packing & Delivery
UTECH have professional design team and technical person, any machine size and appearance all can customized for you. UTECH have Cnc Router Series, include Mini Desktop Cnc Router, Advertising Cnc Router, Woodworking Cnc Router, Professional Stone Cnc Router, Sign Cnc Router, ATC Cnc Router; Vision Localization/CCD Series include Cnc Router with CCD, Oscillating Knife Cutter with CCD.
Shandong U-May CNC Technology Co., Ltd.
Shandong U-MAY CNC Technology CO.,LTD.Specializes in the research, development, production of CNC MACHINE. Our brand "WIN" "UTECH" hava a considerable reputation in the domestic similar products, which has been widely used in wooden furniture, advertising, craft gifts, packaging and printing, logo and etc. Our products have been exported to many countries and regions such as Europe, Russia, Asia, Africa. We are committed to the enterprise management philosophy "Integrity - based, constantly innovation,effective communication,quality services" and the goal of "Technical service customer", but also great attention to product design , manufacture , installation , adjustment. We will still try our best to maintain one stop professional service.
- Company Name: Shandong U-May CNC Technology Co., Ltd.
- Representative: Xin Li
- Product/Service: Cnc Router , Laser Engraving Cutting Machine , Oscillating Knife Cutting Machine , Fiber Laser Cutting Machine , Plasma Cutting Machine , Fiber Laser Marking Machine
- Capital (Million US $): 叁佰贰拾万元整
- Year Established: 2014
- Total Annual Sales Volume (Million US $): US$1 Million - US$2.5 Million
- Export Percentage: 71% - 80%
- Total Annual Purchase Volume (Million US $): US$2.5 Million - US$5 Million
- No. of Production Lines: 5
- No. of R&D Staff: 21 -30 People
- No. of QC Staff: 5 -10 People
- OEM Services Provided: yes
- Factory Size (Sq.meters): 1,000-3,000 square meters
- Factory Location: No. 6-8, Industry South Road, Licheng District, Jinan, Shandong, China (Mainland)
- Contact Person: Ms. Sofia
- Tel: 86-186-63716521
